Battery Pack Parameters:

Model: GSK-R6250-A

Battery Pack: 17S1P

Size (L*W*H)mm: 160x190x360mm

Weight (kg): About 21Kg

Battery Type: Li-NiCoMn

Rated Voltage: 62.9V 3145W

Rated Power:3145wh

NominalCapacity:50Ah

Actual capacity: ≥50Ah

Operating Voltage Range: 47.6V-71.4V

Standard charging current: 15A

Maximum continuous charging current:30A

Maximum continuous  discharge current:55A

Peak Discharge Current: 180A(200mS)

Charge cut-off voltage: 71.4V

Discharge cut-off voltage: 46.75V

Internal Resistance (mΩ): ≤20mΩ

Battery Cycle Life: 1500 times (0.5C standard charge and discharge)

Waterproof Level: IP53

Cooling Mode: Natural Cooling

Transport voltage: 61.2V-63.75V

GPS: Support

Communication Method: Bluetooth, GSM-LTE, RS485

Operating Temperature:Charge -5-55℃ ,Discharge -15-60℃, Storage -10-40℃
